| Main Features |
◎ Variety of protocols supported: PMBus, MODBUS, RS232/485, and I2C ◎ Smart GUI to set and monitoring the power supplies remotely |
| Rated Power |
1500W |
| DC Output Voltage |
12V; 15V; 24V; 30V; 36V; 48V; 57V |
| DC Output Quantity |
Single |
| Rated Current |
125A; 100A; 62.5A; 50A; 41.7A; 31.3A; 26.3A |
| Ripple & Noise (Max.) |
150mVp-p (12V) |
| Input Voltage Range |
90 ~ 264VAC, 250~370VDC |
| Inrush Current (Typ.) |
30A / 115VAC, 45A / 230VAC (cold start) |
| Function |
Auxiliary power; Remote ON/OFF control; Power OK signal; Output voltage and current trim (C11 only) |
| Parallel Connection |
Yes (coming soon) |
| Protection |
Over Load / Over Voltage / Over Temperature / Short Circuit / Fan Failure |
| Cooling |
Load and temperature control fan |
| Efficiency |
93% |
| Operating Temperature |
-20~60℃ |
| Storage Temp. & Humidity |
-40~85℃, 10~95%RH |
| Safety |
TUV / UL / CE / UKCA / CB |
| Dimension (WxHxD) |
127.8x64x280.4 mm / 5.03x2.52x11.04 inch |
| Weight (Net) |
2.2kg |
